pgpa_join.c File Reference

#include "postgres.h"
#include "pgpa_join.h"
#include "pgpa_scan.h"
#include "pgpa_walker.h"
#include "nodes/pathnodes.h"
#include "nodes/print.h"
#include "parser/parsetree.h"

Include dependency graph for pgpa_join.c:

Go to the source code of this file.

Data Structures
struct	pgpa_join_unroller

Functions
static pgpa_join_strategy	pgpa_decompose_join (pgpa_plan_walker_context *walker, Plan *plan, Plan **realouter, Plan **realinner, ElidedNode **elidedrealouter, ElidedNode **elidedrealinner, bool *found_any_outer_gather, bool *found_any_inner_gather)
static ElidedNode *	pgpa_descend_node (PlannedStmt *pstmt, Plan **plan)
static ElidedNode *	pgpa_descend_any_gather (PlannedStmt *pstmt, Plan **plan, bool *found_any_gather)
static bool	pgpa_descend_any_unique (PlannedStmt *pstmt, Plan **plan, ElidedNode **elided_node)
static bool	is_result_node_with_child (Plan *plan)
static bool	is_sorting_plan (Plan *plan)
pgpa_join_unroller *	pgpa_create_join_unroller (void)
void	pgpa_unroll_join (pgpa_plan_walker_context *walker, Plan *plan, bool beneath_any_gather, pgpa_join_unroller *join_unroller, pgpa_join_unroller **outer_join_unroller, pgpa_join_unroller **inner_join_unroller)
pgpa_unrolled_join *	pgpa_build_unrolled_join (pgpa_plan_walker_context *walker, pgpa_join_unroller *join_unroller)
void	pgpa_destroy_join_unroller (pgpa_join_unroller *join_unroller)

Function Documentation

is_result_node_with_child()

static bool is_result_node_with_child ( Plan *  plan )

static

Definition at line 630 of file pgpa_join.c.

{
    return IsA(plan, Result) && plan->lefttree != NULL;
}

References fb(), IsA, and plan.

Referenced by pgpa_decompose_join(), and pgpa_unroll_join().

is_sorting_plan()

static bool is_sorting_plan ( Plan *  plan )

static

Definition at line 639 of file pgpa_join.c.

{
    return IsA(plan, Sort) || IsA(plan, IncrementalSort);
}

References IsA, and plan.

Referenced by pgpa_decompose_join(), pgpa_descend_any_gather(), pgpa_descend_any_unique(), and pgpa_unroll_join().

pgpa_build_unrolled_join()

pgpa_unrolled_join * pgpa_build_unrolled_join	(	pgpa_plan_walker_context *	walker,
		pgpa_join_unroller *	join_unroller
	)

Definition at line 230 of file pgpa_join.c.

{
    pgpa_unrolled_join *ujoin;
    int         i;

    /*
     * We shouldn't have gone even so far as to create a join unroller unless
     * we found at least one unrollable join.
     */
    Assert(join_unroller->nused > 0);

    /* Allocate result structures. */
    ujoin = palloc0_object(pgpa_unrolled_join);
    ujoin->ninner = join_unroller->nused;
    ujoin->strategy = palloc0_array(pgpa_join_strategy, join_unroller->nused);
    ujoin->inner = palloc0_array(pgpa_join_member, join_unroller->nused);

    /* Handle the outermost join. */
    ujoin->outer.plan = join_unroller->outer_subplan;
    ujoin->outer.elided_node = join_unroller->outer_elided_node;
    ujoin->outer.scan =
        pgpa_build_scan(walker, ujoin->outer.plan,
                        ujoin->outer.elided_node,
                        join_unroller->outer_beneath_any_gather,
                        true);

    /*
     * We want the joins from the deepest part of the plan tree to appear
     * first in the result object, but the join unroller adds them in exactly
     * the reverse of that order, so we need to flip the order of the arrays
     * when constructing the final result.
     */
    for (i = 0; i < join_unroller->nused; ++i)
    {
        int         k = join_unroller->nused - i - 1;

        /* Copy strategy, Plan, and ElidedNode. */
        ujoin->strategy[i] = join_unroller->strategy[k];
        ujoin->inner[i].plan = join_unroller->inner_subplans[k];
        ujoin->inner[i].elided_node = join_unroller->inner_elided_nodes[k];

        /*
         * Fill in remaining details, using either the nested join unroller,
         * or by deriving them from the plan and elided nodes.
         */
        if (join_unroller->inner_unrollers[k] != NULL)
            ujoin->inner[i].unrolled_join =
                pgpa_build_unrolled_join(walker,
                                         join_unroller->inner_unrollers[k]);
        else
            ujoin->inner[i].scan =
                pgpa_build_scan(walker, ujoin->inner[i].plan,
                                ujoin->inner[i].elided_node,
                                join_unroller->inner_beneath_any_gather[k],
                                true);
    }

    return ujoin;
}

References Assert, fb(), i, palloc0_array, palloc0_object, pgpa_build_scan(), and pgpa_build_unrolled_join().

Referenced by pgpa_build_unrolled_join(), and pgpa_walk_recursively().

pgpa_create_join_unroller()

pgpa_join_unroller * pgpa_create_join_unroller

(

void

)

Definition at line 64 of file pgpa_join.c.

{
    pgpa_join_unroller *join_unroller;

    join_unroller = palloc0_object(pgpa_join_unroller);
    join_unroller->nallocated = 4;
    join_unroller->strategy =
        palloc_array(pgpa_join_strategy, join_unroller->nallocated);
    join_unroller->inner_subplans =
        palloc_array(Plan *, join_unroller->nallocated);
    join_unroller->inner_elided_nodes =
        palloc_array(ElidedNode *, join_unroller->nallocated);
    join_unroller->inner_unrollers =
        palloc_array(pgpa_join_unroller *, join_unroller->nallocated);
    join_unroller->inner_beneath_any_gather =
        palloc_array(bool, join_unroller->nallocated);

    return join_unroller;
}

References fb(), pgpa_join_unroller::nallocated, palloc0_object, and palloc_array.

Referenced by pgpa_unroll_join(), and pgpa_walk_recursively().

pgpa_decompose_join()

static pgpa_join_strategy pgpa_decompose_join ( pgpa_plan_walker_context *  walker, Plan *  plan, Plan **  realouter, Plan **  realinner, ElidedNode **  elidedrealouter, ElidedNode **  elidedrealinner, bool *  found_any_outer_gather, bool *  found_any_inner_gather  )

static

Definition at line 339 of file pgpa_join.c.

{
    PlannedStmt *pstmt = walker->pstmt;
    JoinType    jointype = ((Join *) plan)->jointype;
    Plan       *outerplan = plan->lefttree;
    Plan       *innerplan = plan->righttree;
    ElidedNode *elidedouter;
    ElidedNode *elidedinner;
    pgpa_join_strategy strategy;
    bool        uniqueouter;
    bool        uniqueinner;

    elidedouter = pgpa_last_elided_node(pstmt, outerplan);
    elidedinner = pgpa_last_elided_node(pstmt, innerplan);
    *found_any_outer_gather = false;
    *found_any_inner_gather = false;

    switch (nodeTag(plan))
    {
        case T_MergeJoin:

            /*
             * The planner may have chosen to place a Material node on the
             * inner side of the MergeJoin; if this is present, we record it
             * as part of the join strategy. (However, scan-level Materialize
             * nodes are an exception.)
             */
            if (elidedinner == NULL && IsA(innerplan, Material) &&
                !pgpa_is_scan_level_materialize(innerplan))
            {
                elidedinner = pgpa_descend_node(pstmt, &innerplan);
                strategy = JSTRAT_MERGE_JOIN_MATERIALIZE;
            }
            else
                strategy = JSTRAT_MERGE_JOIN_PLAIN;

            /*
             * For a MergeJoin, either the outer or the inner subplan, or
             * both, may have needed to be sorted; we must disregard any Sort
             * or IncrementalSort node to find the real inner or outer
             * subplan.
             */
            if (elidedouter == NULL && is_sorting_plan(outerplan))
                elidedouter = pgpa_descend_node(pstmt, &outerplan);
            if (elidedinner == NULL && is_sorting_plan(innerplan))
                elidedinner = pgpa_descend_node(pstmt, &innerplan);
            break;

        case T_NestLoop:

            /*
             * The planner may have chosen to place a Material or Memoize node
             * on the inner side of the NestLoop; if this is present, we
             * record it as part of the join strategy. (However, scan-level
             * Materialize nodes are an exception.)
             */
            if (elidedinner == NULL && IsA(innerplan, Material) &&
                !pgpa_is_scan_level_materialize(innerplan))
            {
                elidedinner = pgpa_descend_node(pstmt, &innerplan);
                strategy = JSTRAT_NESTED_LOOP_MATERIALIZE;
            }
            else if (elidedinner == NULL && IsA(innerplan, Memoize))
            {
                elidedinner = pgpa_descend_node(pstmt, &innerplan);
                strategy = JSTRAT_NESTED_LOOP_MEMOIZE;
            }
            else
                strategy = JSTRAT_NESTED_LOOP_PLAIN;
            break;

        case T_HashJoin:

            /*
             * The inner subplan of a HashJoin is always a Hash node; the real
             * inner subplan is the Hash node's child.
             */
            Assert(IsA(innerplan, Hash));
            Assert(elidedinner == NULL);
            elidedinner = pgpa_descend_node(pstmt, &innerplan);
            strategy = JSTRAT_HASH_JOIN;
            break;

        default:
            elog(ERROR, "unrecognized node type: %d", (int) nodeTag(plan));
    }

    /*
     * The planner may have decided to implement a semijoin by first making
     * the nullable side of the plan unique, and then performing a normal join
     * against the result. Therefore, we might need to descend through a
     * unique node on either side of the plan.
     */
    uniqueouter = pgpa_descend_any_unique(pstmt, &outerplan, &elidedouter);
    uniqueinner = pgpa_descend_any_unique(pstmt, &innerplan, &elidedinner);

    /*
     * Can we see a Result node here, to project above a Gather? So far I've
     * found no example that behaves that way; rather, the Gather or Gather
     * Merge is made to project. Hence, don't test is_result_node_with_child()
     * at this point.
     */

    /*
     * The planner may have decided to parallelize part of the join tree, so
     * we could find a Gather or Gather Merge node here. Note that, if
     * present, this will appear below nodes we considered as part of the join
     * strategy, but we could find another uniqueness-enforcing node below the
     * Gather or Gather Merge, if present.
     */
    if (elidedouter == NULL)
    {
        elidedouter = pgpa_descend_any_gather(pstmt, &outerplan,
                                              found_any_outer_gather);
        if (*found_any_outer_gather &&
            pgpa_descend_any_unique(pstmt, &outerplan, &elidedouter))
            uniqueouter = true;
    }
    if (elidedinner == NULL)
    {
        elidedinner = pgpa_descend_any_gather(pstmt, &innerplan,
                                              found_any_inner_gather);
        if (*found_any_inner_gather &&
            pgpa_descend_any_unique(pstmt, &innerplan, &elidedinner))
            uniqueinner = true;
    }

    /*
     * It's possible that a Result node has been inserted either to project a
     * target list or to implement a one-time filter. If so, we can descend
     * through it. Note that a Result node without a child would be a
     * degenerate scan or join, and not something we could descend through.
     */
    if (elidedouter == NULL && is_result_node_with_child(outerplan))
        elidedouter = pgpa_descend_node(pstmt, &outerplan);
    if (elidedinner == NULL && is_result_node_with_child(innerplan))
        elidedinner = pgpa_descend_node(pstmt, &innerplan);

    /*
     * If this is a semijoin that was converted to an inner join by making one
     * side or the other unique, make a note that the inner or outer subplan,
     * as appropriate, should be treated as a query plan feature when the main
     * tree traversal reaches it.
     *
     * Conversely, if the planner could have made one side of the join unique
     * and thereby converted it to an inner join, and chose not to do so, that
     * is also worth noting.
     *
     * NB: This code could appear slightly higher up in this function, but
     * none of the nodes through which we just descended should have
     * associated RTIs.
     *
     * NB: This seems like a somewhat hacky way of passing information up to
     * the main tree walk, but I don't currently have a better idea.
     */
    if (uniqueouter)
        pgpa_add_future_feature(walker, PGPAQF_SEMIJOIN_UNIQUE, outerplan);
    else if (jointype == JOIN_RIGHT_SEMI)
        pgpa_add_future_feature(walker, PGPAQF_SEMIJOIN_NON_UNIQUE, outerplan);
    if (uniqueinner)
        pgpa_add_future_feature(walker, PGPAQF_SEMIJOIN_UNIQUE, innerplan);
    else if (jointype == JOIN_SEMI)
        pgpa_add_future_feature(walker, PGPAQF_SEMIJOIN_NON_UNIQUE, innerplan);

    /* Set output parameters. */
    *realouter = outerplan;
    *realinner = innerplan;
    *elidedrealouter = elidedouter;
    *elidedrealinner = elidedinner;
    return strategy;
}

References Assert, elog, ERROR, fb(), is_result_node_with_child(), is_sorting_plan(), IsA, JOIN_RIGHT_SEMI, JOIN_SEMI, JSTRAT_HASH_JOIN, JSTRAT_MERGE_JOIN_MATERIALIZE, JSTRAT_MERGE_JOIN_PLAIN, JSTRAT_NESTED_LOOP_MATERIALIZE, JSTRAT_NESTED_LOOP_MEMOIZE, JSTRAT_NESTED_LOOP_PLAIN, Plan::lefttree, nodeTag, pgpa_add_future_feature(), pgpa_descend_any_gather(), pgpa_descend_any_unique(), pgpa_descend_node(), pgpa_is_scan_level_materialize(), pgpa_last_elided_node(), PGPAQF_SEMIJOIN_NON_UNIQUE, PGPAQF_SEMIJOIN_UNIQUE, plan, and Plan::righttree.

Referenced by pgpa_unroll_join().

pgpa_descend_any_gather()

static ElidedNode * pgpa_descend_any_gather ( PlannedStmt *  pstmt, Plan **  plan, bool *  found_any_gather  )

static

Definition at line 540 of file pgpa_join.c.

{
    if (IsA(*plan, Gather))
    {
        *found_any_gather = true;
        return pgpa_descend_node(pstmt, plan);
    }

    if (IsA(*plan, GatherMerge))
    {
        ElidedNode *elided = pgpa_descend_node(pstmt, plan);

        if (elided == NULL && is_sorting_plan(*plan))
            elided = pgpa_descend_node(pstmt, plan);

        *found_any_gather = true;
        return elided;
    }

    return NULL;
}

References fb(), is_sorting_plan(), IsA, pgpa_descend_node(), and plan.

Referenced by pgpa_decompose_join().

pgpa_descend_any_unique()

static bool pgpa_descend_any_unique ( PlannedStmt *  pstmt, Plan **  plan, ElidedNode **  elided_node  )

static

Definition at line 581 of file pgpa_join.c.

{
    bool        descend = false;
    bool        sjunique = false;

    if (*elided_node != NULL)
        return sjunique;

    if (IsA(*plan, Unique))
    {
        descend = true;
        sjunique = true;
    }
    else if (IsA(*plan, Agg))
    {
        /*
         * If this is a simple Agg node, then assume it's here to implement
         * semijoin uniqueness. Otherwise, assume it's completing an eager
         * aggregation or partitionwise aggregation operation that began at a
         * higher level of the plan tree.
         *
         * (Note that when we're using an Agg node for uniqueness, there's no
         * need for any case other than AGGSPLIT_SIMPLE, because there's no
         * aggregated column being computed. However, the fact that
         * AGGSPLIT_SIMPLE is in use doesn't prove that this Agg is here for
         * the semijoin uniqueness. Maybe we should adjust an Agg node to
         * carry a "purpose" field so that code like this can be more certain
         * of its analysis.)
         */
        descend = true;
        sjunique = (((Agg *) *plan)->aggsplit == AGGSPLIT_SIMPLE);
    }

    if (descend)
    {
        *elided_node = pgpa_descend_node(pstmt, plan);

        if (*elided_node == NULL && is_sorting_plan(*plan))
            *elided_node = pgpa_descend_node(pstmt, plan);
    }

    return sjunique;
}

References AGGSPLIT_SIMPLE, fb(), is_sorting_plan(), IsA, pgpa_descend_node(), and plan.

Referenced by pgpa_decompose_join().

pgpa_descend_node()

static ElidedNode * pgpa_descend_node ( PlannedStmt *  pstmt, Plan **  plan  )

static

Definition at line 522 of file pgpa_join.c.

{
    *plan = (*plan)->lefttree;
    return pgpa_last_elided_node(pstmt, *plan);
}

References pgpa_last_elided_node(), and plan.

Referenced by pgpa_decompose_join(), pgpa_descend_any_gather(), and pgpa_descend_any_unique().

pgpa_destroy_join_unroller()

void pgpa_destroy_join_unroller

(

pgpa_join_unroller *

join_unroller

)

Definition at line 295 of file pgpa_join.c.

{
    pfree(join_unroller->strategy);
    pfree(join_unroller->inner_subplans);
    pfree(join_unroller->inner_elided_nodes);
    pfree(join_unroller->inner_unrollers);
    pfree(join_unroller->inner_beneath_any_gather);
    pfree(join_unroller);
}

References fb(), and pfree().

Referenced by pgpa_walk_recursively().

pgpa_unroll_join()

void pgpa_unroll_join	(	pgpa_plan_walker_context *	walker,
		Plan *	plan,
		bool	beneath_any_gather,
		pgpa_join_unroller *	join_unroller,
		pgpa_join_unroller **	outer_join_unroller,
		pgpa_join_unroller **	inner_join_unroller
	)

Definition at line 105 of file pgpa_join.c.

{
    pgpa_join_strategy strategy;
    Plan       *realinner,
               *realouter;
    ElidedNode *elidedinner,
               *elidedouter;
    int         n;
    bool        found_any_outer_gather = false;
    bool        found_any_inner_gather = false;

    Assert(join_unroller != NULL);

    /*
     * We need to pass the join_unroller object down through certain types of
     * plan nodes -- anything that's considered part of the join strategy, and
     * any other nodes that can occur in a join tree despite not being scans
     * or joins.
     *
     * This includes:
     *
     * (1) Materialize, Memoize, and Hash nodes, which are part of the join
     * strategy,
     *
     * (2) Gather and Gather Merge nodes, which can occur at any point in the
     * join tree where the planner decided to initiate parallelism,
     *
     * (3) Sort and IncrementalSort nodes, which can occur beneath MergeJoin
     * or GatherMerge,
     *
     * (4) Agg and Unique nodes, which can occur when we decide to make the
     * nullable side of a semijoin unique and then join the result, and
     *
     * (5) Result nodes with children, which can be added either to project to
     * enforce a one-time filter (but Result nodes without children are
     * degenerate scans or joins).
     */
    if (IsA(plan, Material) || IsA(plan, Memoize) || IsA(plan, Hash)
        || IsA(plan, Gather) || IsA(plan, GatherMerge)
        || is_sorting_plan(plan) || IsA(plan, Agg) || IsA(plan, Unique)
        || is_result_node_with_child(plan))
    {
        *outer_join_unroller = join_unroller;
        return;
    }

    /*
     * Since we've already handled nodes that require pass-through treatment,
     * this should be an unrollable join.
     */
    strategy = pgpa_decompose_join(walker, plan,
                                   &realouter, &realinner,
                                   &elidedouter, &elidedinner,
                                   &found_any_outer_gather,
                                   &found_any_inner_gather);

    /* If our workspace is full, expand it. */
    if (join_unroller->nused >= join_unroller->nallocated)
    {
        join_unroller->nallocated *= 2;
        join_unroller->strategy =
            repalloc_array(join_unroller->strategy,
                           pgpa_join_strategy,
                           join_unroller->nallocated);
        join_unroller->inner_subplans =
            repalloc_array(join_unroller->inner_subplans,
                           Plan *,
                           join_unroller->nallocated);
        join_unroller->inner_elided_nodes =
            repalloc_array(join_unroller->inner_elided_nodes,
                           ElidedNode *,
                           join_unroller->nallocated);
        join_unroller->inner_beneath_any_gather =
            repalloc_array(join_unroller->inner_beneath_any_gather,
                           bool,
                           join_unroller->nallocated);
        join_unroller->inner_unrollers =
            repalloc_array(join_unroller->inner_unrollers,
                           pgpa_join_unroller *,
                           join_unroller->nallocated);
    }

    /*
     * Since we're flattening outer-deep join trees, it follows that if the
     * outer side is still an unrollable join, it should be unrolled into this
     * same object. Otherwise, we've reached the limit of what we can unroll
     * into this object and must remember the outer side as the final outer
     * subplan.
     */
    if (elidedouter == NULL && pgpa_is_join(realouter))
        *outer_join_unroller = join_unroller;
    else
    {
        join_unroller->outer_subplan = realouter;
        join_unroller->outer_elided_node = elidedouter;
        join_unroller->outer_beneath_any_gather =
            beneath_any_gather || found_any_outer_gather;
    }

    /*
     * Store the inner subplan. If it's an unrollable join, it needs to be
     * flattened in turn, but into a new unroller object, not this one.
     */
    n = join_unroller->nused++;
    join_unroller->strategy[n] = strategy;
    join_unroller->inner_subplans[n] = realinner;
    join_unroller->inner_elided_nodes[n] = elidedinner;
    join_unroller->inner_beneath_any_gather[n] =
        beneath_any_gather || found_any_inner_gather;
    if (elidedinner == NULL && pgpa_is_join(realinner))
        *inner_join_unroller = pgpa_create_join_unroller();
    else
        *inner_join_unroller = NULL;
    join_unroller->inner_unrollers[n] = *inner_join_unroller;
}

References Assert, fb(), is_result_node_with_child(), is_sorting_plan(), IsA, pgpa_join_unroller::nallocated, pgpa_create_join_unroller(), pgpa_decompose_join(), pgpa_is_join(), plan, and repalloc_array.

Referenced by pgpa_walk_recursively().
